Style Name: New Standard Plus
Style Number: RR014
Thickness: 5.0mm
Wear Layer: 12mil
Core Thickness: 4.0mm
Core Density: 1970
Attached Underlayment: 1mm IXPE
Embossing: UV
Surface Finish: BPC-Medium Emboss
Nominal Dimensions: 7"W x 48"L
Actual Dimensions: 7"W x 48"L (180mm W x 1220mmL)
Pattern Repeat: 5
Edge: Painted bevel
Gloss Level: Matte
Traffic: Residential, Commercial
Antimicrobial: Yes
Locking Mechanism: I4F
PACKAGING
Pieces per carton: 10
Boxes per pallet: 55
Square feet per carton: 23.64
Square feet per pallet: 1,300.2
Weight per carton: 39.70 lbs
Weight per pallet: 2,286.01 lbs
Pallet dimensions: 48.8" x 38.6" x 29.9"
TECHNICAL
STC Sound Rating (ASTM E90): 53
Static Load (ASTM F970): 1,400 psi (<.005")
IIC Sound Rating (ASTM E492): 62
Residual Indentation (ASTM F1419): Passes
Dimensional Stability (ASTM F2199): Passes Chemical Resistance (ASTM F925): Passes
Resistance to heat (ASTM F1514): Passes Resistance to light (ASTM F1515): Passes
Critical Radiant Flux (ASTM E648): Class 1 Optical Smoke Density (ASTM E662): <450
Slip Resistance (ASTM C1028): ADA compliant FloorScore Certified: Yes
WARRANTY
Lifetime Residential * 7 Year Commercial * Lifetime Waterproof and Pet
